SAME Hercules 160
| 1979 - 1983 |
Row-Crop tractor |
|
Production |
Manufacturer: | SAME
|
Type: | Row-Crop tractor
|
SAME Hercules 160 Power |
Engine: | 160 hp 119.3 kW
|
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Differential lock: | mechanical rear
|
Steering: | power
|
Brakes: | hydraulic wet disc
|
Cab: | Cab standard with heater. Air-conditioning optional.
|
Transmissions: | 12-speed synchronized
|
| 24-speed creeper
|
Transmission details ... |
Hydraulics |
Pump flow: | 15.9 gpm 60.2 lpm
|
Tractor hitch |
Rear Type: | II
|
Rear lift: | 11000 lbs 4989 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Clutch: | hydraulic wet disc
|
Rear RPM: | 540/1000 (1.375)
|
