AGCO Allis 9635
| | 1994 - 1997 |
| 9600 Series | | Row-Crop tractor |
|
Series map:
9635
9655
150.0hp*
172.2hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | AGCO Allis
|
| Row-Crop tractor |
| Original price was $76,000 in 1997 |
| Variants |
| 9435 | 32-speed semi-powershift
|
| 9635 | 18-speed full powershift
|
| AGCO Allis 9635 Power |
| PTO (claimed) | 135 hp
100.7 kW
|
| Drawbar (tested) | 112.29 hp
83.7 kW
|
| PTO (tested) | 141.63 hp
105.6 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Hydraulics |
| Type | closed center
|
| Pressure | 2250 psi
155.1 bar
|
| Rear valves | 3 or 4
|
| Pump flow | 22 gpm
83.3 lpm
|
| Tractor hitch |
| Rear Type | III/II
|
| Control | lower-link draft sensing
|
| Rear lift (at 24"/610mm) | 7212 lbs
3271 kg
|
| | 8544 lbsOptOptional
3875 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear RPM | 540/1000 (1.375)
|
| Engine RPM | 540@2228
1000@2200
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Batteries | 2
|
| Battery volts | 12
|
| References |
 |
| 9600/9800 Series Tractors published by AGCO |
