AGCO Allis 9170
| | 1991 - 1992 |
| 9100 Series | | Row-Crop tractor | | White built |
|
Series map:
9150
9170
9190
166.7hp*
192.2hp*
214.4hp*
*Estimated engine power for comparison only.
| Production |
| Distributor | AGCO Allis
|
| Manufacturer | White
|
| Row-Crop tractor |
| Built in Coldwater, Ohio, USA |
| Original price was $68,000 in 1992 |
| AGCO Allis 9170 Power |
| Drawbar (claimed) | 154 hp
114.8 kW
|
| PTO (claimed) | 173 hp
129.0 kW
|
| Drawbar (tested) | 155.86 hp
116.2 kW
|
| PTO (tested) | 173.37 hp
129.3 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Hydraulics |
| Type | closed center
|
| Pressure | 2500 psi
172.4 bar
|
| Valves | 2 or 3
|
| Pump flow | 24 gpm
90.8 lpm
|
| Tractor hitch |
| Rear Type | III/II
|
| Control | position and draft control
|
| Rear lift (at ends) | 7628 lbs
3460 kg
|
| | 88746 lbsOptOptional
40255 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1.75)
|
| Engine RPM | 1000@2168
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 105
|
| Batteries | 2
|
| Battery volts | 12
|
| References |
 |
| 9100 Series published in 1991, by AGCO |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on January 21, 2024 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
AGCO Allis 9170 photos...
Full dimensions and tires ...
