AGCO Allis 8785

AGCO Allis 8785 tractor photo
1998 - 1999
Row-Crop tractor
Next model:AGCO RT115
Series back:AGCO Allis 8775






Production:

Manufacturer:AGCO
Original price (USD)
   $54,000 (1999 )


AGCO Allis 8785 Engine:

   Sisu Diesel 6.6L 6-cyl diesel
full engine details ...


Capacity:

Fuel:42 gal [159.0 L]


3-Point Hitch:

Rear Type:II
Rear lift:9000 lbs [4082 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:112.6 inches [286 cm]
Weight:12450 lbs [5647 kg]
Front tire:11.00-16
Rear tire:18.4R38
full dimensions and tires ...


8785 Serial Numbers:

Location:Console, right side
1998: G01001
1999: G01001

how to read serial numbers...



AGCO Allis 8785 Power:

PTO (claimed):110 hp [82.0 kW]
PTO (tested):112.34 hp [83.8 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Cab:Cab standard. ROPS available.


Hydraulics:

Type:closed center
Valves:2
Pump flow:27.7 gpm [104.8 lpm]


Electrical:

Ground:negative


Battery:

Volts:12
