| | 1958 - 1959 |
| 200B Series | | Utility tractor |
|
| Transmissions overview |
| 4-speed gear |
| 12-speed gear |
| 8-speed mechanical shuttle |
| Transmission |
| Type: | gear
|
| Gears: | 4 forward and 1 reverse
|
| Clutch: | 235mm dry disc
|
| Oil capacity: | 28 qts
26.5 L
|
| Speeds |
| With 10-24 rear tires. |
|
| Transmission |
| Transmission: | Tripl-Range
|
| Type: | gear
|
| Gears: | 12 forward and 3 reverse
|
| Clutch: | 235mm dry disc
|
| Speeds |
| With 10-24 rear tires. |
|
| Transmission |
| Type: | mechanical shuttle
|
| Gears: | 8 forward and reverse
|
| Clutch: | 235mm dry disc
|
| Oil capacity: | L1:L2:L3:L4:H1:H2:H3:H4 qts
0.0 L
|
| | 1900:1.4:2.1:2.8:9.3:2.3:3.3:4.5:15.0 qts
1798.2 L
|
