Tractors > Zetor > 5745

Zetor 5745

No photo available
1972 - 1978   UR1 7 Series
Series next:Zetor 6745






Production:

Manufacturer:Zetor
Factory:Brno, Czechoslovakia


Variants:

5711:2WD
5718:2WD cab
5745:4WD
5748:4WD cab


Zetor 5745 Engine:

   Zetor 3.1L 4-cyl diesel
full engine details ...


Capacity:

Fuel:18.5 gal [70.0 L]


3-Point Hitch:

Rear lift:3,748 lbs [1700 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/ground
 1000 (optional)


Dimensions & Tires:

Wheelbase:88.46 inches [224 cm]
Weight:6,530 lbs [2962 kg]
Front tire:9.5-24
Rear tire:12.4-36
full dimensions and tires ...


5745 Serial Numbers:


- Serial numbers unknown -



Zetor 5745 Power:

Engine:58 hp [43.3 kW]
PTO (claimed):54 hp [40.3 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Brakes:differential hydraulic drum
Trailer brakes:air optional
Cab:Open operator station.


Hydraulics:

Type:Zetormatic
Pressure:2321 psi [160.0 bar]
Valves:1
Pump flow:5.3 gpm [20.1 lpm]
