Tractors > CaseIH > JX85 Maxxima

CaseIH JX85 Maxxima - transmission

CaseIH JX85 Maxxima tractor photo
2002 - 2006   JX Series
Model years
Utility tractor
Series next:CaseIH JX95
Series back:CaseIH JX75
more CaseIH JX85 Maxxima specifications...






Transmission:

Type:mechanical shuttle
Gears:12 forward and reverse
Four gears (1-4) in three ranges with mechanical shuttle.
Speeds:
JX85 Maxxima  mechanical shuttle speeds


Transmission:

Type:creeper
Gears:20 forward and 12 reverse
