Tractors > CaseIH > JX55 Maxxima

CaseIH JX55 Maxxima - transmission

CaseIH JX55 Maxxima tractor photo
2002 - 2006   JX Series
Model years
Utility tractor
Series next:CaseIH JX65
more CaseIH JX55 Maxxima specifications...






Transmission:

Type:mechanical shuttle
Gears:12 forward and reverse
Clutch:dry disc
Four gears (1-4) in three ranges with mechanical shuttle.
Speeds:
JX55 Maxxima  mechanical shuttle speeds


Transmission:

Type:creeper
Gears:20 forward and 12 reverse
