Tractors > John Deere > 8120

John Deere 8120 - engine

John Deere 8120 tractor photo
2002 - 2005   8020 Series
Row-Crop tractor
Previous model:John Deere 8110
Next model:John Deere 8130
Series next:John Deere 8220
more John Deere 8120 specifications...






Engine Detail:

 John Deere
 turbocharged diesel
 6-cylinder
 liquid-cooled inline
 496 ci [8.1 L]
Bore/Stroke:4.56x5.06 inches [116 x 129 mm]
Rated Power (ECE R24):200 hp [149.1 kW]
Rated Power (EC 97/98):208 hp [155.1 kW]
Maximum Power (ECE R24):220 hp [164.1 kW]
Maximum Power (EC 97/68):230 hp [171.5 kW]
Fuel system:electronic high-pressure common rail (HPCR)
Air cleaner:dry with secondary element
Compression:16.5:1
Rated RPM:2200
Idle RPM:900-2300
Operating RPM:1500-2200
Starter volts:12
Oil capacity:22.7 qts [21.5 L]
Oil change:250 h
Coolant capacity:35.9 qts [34.0 L]
