Belarus 7100


Belarus 7100 tractor photo
1978 - 1992
Four-wheel Drive (4WD) tractor
Production
ManufacturerBelarus
Four-wheel Drive (4WD) tractor
Built in Minsk, Belarus
Variants
K-701similar Kirovets model
Belarus 7100 Engine
Belarus 22.3L 12-cyl diesel
Engine details ...
Belarus 7100 Power
Engine300 hp
223.7 kW
PTO (claimed)260 hp
193.9 kW
Drawbar (tested)249.69 hp
186.2 kW
PTO (tested)269.62 hp
201.1 kW
Performance test details ...
Mechanical
Four-wheel drive
Articulated power steering
Pneumatic drum brakes
Cab standard with heat.
Photos
No photos of the Belarus 7100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel170 gal
643.5 L
Hydraulic system33 gal
124.9 L
Hydraulics
Typeopen center
Capacity33 gal
124.9 L
Valves3
Pump flow33.4 gpm
126.4 lpm
Steering flow46.3 gpm
175.2 lpm
Tractor hitch
Rear TypeIII
Power Take-off (PTO)
Rear PTOindependent OptOptional
Rear RPM1000 (1.75)
Dimensions & Tires
Wheelbase126 inches
320 cm
Weight29735 lbs
13487 kg
Front tire28.1-26
Rear tire28.1-26
Full dimensions and tires ...
Electrical
Charging systemalternator
Charging amps80
References
7100 references literature
7100 published by Belarus
