TractorData.com - information on all makes and models of tractors
Tractors > Belarus > 525

Belarus 525

No photo available
1983 - 1996   Progress Series






Production:

Manufacturer:Belarus
Factory:Minsk, Belarus
Original price (USD):18000 (1996)


Variants:

505:2WD
525:4WD


Belarus 525 Engine:

   MTZ 4.8L 4-cyl diesel
full engine details ...


Capacity:

Fuel:34 gal [128.7 L]
Hydraulic system:4.5 gal [17.0 L]


3-Point Hitch:

Rear Type:2
Rear lift (at ends):3,325 lbs [1508 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/ground


Dimensions & Tires:

Wheelbase:96.5 inches [245 cm]
Weight:8540 lbs [3873 kg]
Front tire:11.20-20
Rear tire:15.5-38
full dimensions and tires ...


525 Serial Numbers:


- Serial numbers unknown -



Belarus 525 Power:

Engine:65 hp [48.5 kW]
PTO (claimed):59 hp [44.0 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:mechanical disc


Hydraulics:

Type:open center
Capacity:4.5 gal [17.0 L]
Pressure:2850 psi [196.5 bar]
Valves:2
Pump flow:9 gpm [34.1 lpm]
Steering flow:5.5 gpm [20.8 lpm]
Steering press.:1500 psi [103.4 bar]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:50


Battery:

Number:2
Cold-cranking amps:900
Volts:6
