Belarus 505 - engine

Belarus 505 tractor photo
1983 - 1990   Progress Series
more Belarus 505 specifications...






Engine Detail:

 MTZ D-60
 diesel
 4-cylinder
 liquid-cooled
 290 ci [4.8 L]
Bore/Stroke:4.33x4.92 inches [110 x 125 mm]
Power:65 hp [48.5 kW]
Air cleaner:oil bath
Compression:16:1
Rated RPM:1800
Torque:197 lb-ft [267.1 Nm]
Torque RPM:1300
Firing order:1-3-4-2
Starter volts:12
Oil capacity:16 qts [15.1 L]
Coolant capacity:21 qts [19.9 L]
Intake valve clearance:0.012 inches [0.305 mm]
Exhaust valve clearance:0.012 inches [0.305 mm]
