Belarus MTZ-102


Belarus MTZ-102 tractor photo
1984 - ????
Row-Crop tractor
Production
ManufacturerBelarus
Row-Crop tractor
Built in Minsk, Belarus
Variants
MTZ-1002WD
Belarus MTZ-102 Power
PTO (claimed)100 hp
74.6 kW
Mechanical
Two- or four-wheel drive
Differential lockhydraulic rear
Power steering
Mechanical dry disc brakes
Capacity
Fuel41.2 gal
155.9 L
Hydraulic system5.8 gal
22.0 L
Hydraulics
Typeopen center
Capacity5.8 gal
22.0 L
Pressure2640 psi
182.0 bar
Valves3
Pump flow16.6 gpm
62.8 lpm
Tractor hitch
Rear TypeII
Rear lift6600 lbs
2993 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540/1000 (1.375)
Dimensions & Tires
2WD Wheelbase98.4 inches
249 cm
4WD Wheelbase101.2 inches
257 cm
Weight8580 to 9020 pounds
Front tire9.00-20
2WD Rear tire18.4-34
Full dimensions and tires ...
Electrical
Charging systemalternator
References
MTZ-102 references literature
The New Generation 100/102 published in 1987, by Belarus
