Belarus MTZ-52


Belarus MTZ-52 tractor photo
1962 - 1985
Row-Crop tractor
Production
Manufacturer:Belarus
Type:Row-Crop tractor
Factory:Minsk, Belarus
Variants
MTZ-50:2WD
MTZ-52:4WD
Belarus MTZ-52 Power
Engine:55 hp
41.0 kW
Belarus MTZ-52 Engine
Belarus 4.7L 4-cyl diesel
Fuel tank:26.4 gal
99.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power assist
Brakes:disc
Cab:Cab standard.
Transmission:9-speed gear
Transmission details ...
Photos
No photos of the Belarus MTZ-52 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Total flow:11.9 gpm
45.0 lpm
Tractor hitch
Rear lift:4,410 lbs
2000 kg
Power Take-off (PTO)
Rear RPM:540/ground
Dimensions & Tires
Wheelbase:96.59 inches
245 cm
Weight:6591 lbs
2989 kg
Front tire:8.3/8-20
Rear tire:13.6/12-38
Full dimensions and tires ...
