Kubota L175 Engine


Kubota L175 tractor photo
1973 - 1976
Sub-Compact Utility tractor
Engine Detail
Kubota Z750-A
diesel
2-cylinder
liquid-cooled
Displacement45.3 ci
0.7 L
Bore/Stroke3.00x3.219 inches
76 x 82 mm
Power17 hp
12.7 kW
Compression21:1
Rated RPM2800
Starter volts12
Oil capacity3.7 qts
3.5 L
Coolant capacity5.6 qts
5.3 L
Intake valve clearance0.008 inches (cold)
0.203 mm
Exhaust valve clearance0.008 inches (cold)
0.203 mm
