Tractors > CaseIH > 9250

CaseIH 9250 Tests



CaseIH 9250 tractor photo
1990 - 1995
9200 Series
Four-wheel Drive (4WD) tractor
Series map:
9240
9250
9260
235.0hp
300.0hp
300.0hp
OCED Tractor Test 1651
9250 fuel use from test 96
OCED Tractor Test 1651
Diesel 12-speed 4WD
September 19 - 25, 1991
Link: OCED Tractor Test 1651 file
PTO performance
Max power271.01 hp
202.1 kW
Fuel use14.3 gal/hour
54.1 l/hour
Power at rated engine speed266.01 hp
198.4 kW
Fuel use14.6 gal/hour
55.3 l/hour
Drawbar performance
Max power237.29 hp
176.9 kW
Fuel use14.5 gal/hour
54.9 l/hour
Gear 5 used for power test.
Max pull32,363 lbs
14679 kg
Gear 1 used for pull test.
