Steiger Tiger IV KP-525 Transmission


Steiger Tiger IV KP-525 tractor photo
1984 - 1986
IV Series
Four-wheel Drive (4WD) tractor
Series map:
Tiger IV KP-525
525.0hp
Transmission
TransmissionAllison CLT 5961
Typesix-speed power shift
Gears24 forward and 4 reverse
Six-speed power shift transmission with four-speed transfer case and torque converter.
Speeds
Tiger IV KP-525 CLT 5961 six-speed power shift speeds
