Ford-New Holland 8730 Engine
|
|
Note: the Ford-New Holland model 8730 is the same as the Ford 8730. The following data is from the 8730 listing. |
| Engine Detail | |
| Ford | |
| turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 401 ci 6.6 L |
| Bore/Stroke: | 4.40x4.40 inches 112 x 112 mm |
| Compression: | 15.6:1 |
| Rated RPM: | 2200 |
| Firing order: | 1-5-3-6-2-4 |
| Coolant capacity: | 22 qts 20.8 L |
| 23.6 qts 22.3 L (with heater) | |
| Intake valve clearance: | 0.014-0.016 inches 0.356 mm (cold) |
| Exhaust valve clearance: | 0.017-0.019 inches 0.432 mm (cold) |
| Engine Oil | |
| |
| Oil capacity: | 19.6 qts 18.5 L |
