Tractors > J.I. Case > 1032

J.I. Case 1032

J.I. Case 1032 tractor photo
1966 - 1969   1030 Series
Standard-tread tractor





The J.I. Case 1030 Western Special was Case model 1032. As compared to the general-purpose model 1031, the Western Special had a shorter wheelbase, large fenders and an optional wide-swing drawbar.


Production:

Manufacturer:J.I. Case
Factory:Racine, Wisconsin, USA
Total built:13,763 (all types)
Original price (USD)
   $10,300 (1969 )


Variants:

1031:1030 General-Purpose
1032:1030 Western Special


J.I. Case 1032 Engine:

   J.I. Case 7.4L 6-cyl diesel
full engine details ...


Capacity:

Fuel:48 gal [181.7 L]


3-Point Hitch:

Rear Type:II*Optional


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540
 1000
Engine RPM:1000@1700


Dimensions & Tires:

Wheelbase:90 inches [228 cm]
Weight:9,335 lbs [4234 kg]
Front tire:7.50x16
Rear tire:15.5x38
full dimensions and tires ...


1032 Serial Numbers:

Location:Tractor's instrument panel.
1966: 8279001
1967: 8306501
1968: 8332101
1969: 8356251

how to read serial numbers...



J.I. Case 1032 Power:

Plows:7
Drawbar (tested):88.34 hp [65.9 kW]
PTO (tested):101.79 hp [75.9 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
Steering:power
Brakes:disc
Cab:Open operator station.


Hydraulics:

Valves:2
Pump flow:12 gpm [45.4 lpm]


Battery:

Volts:12
