| | Production: |
| Manufacturer: | Ford
|
| Factory: | Highland Park, Michigan, USA
|
| | Variants: |
| 981: | row-crop chassis
|
| 811: | Select-O-Speed, no PTO
|
| 821: | Four-speed, no PTO or 3-point
|
| 841: | Four-speed
|
| 851: | Five-speed
|
| 861: | Five speed, live PTO
|
| 871: | Select-O-Speed
|
| 881: | Select-O-Speed, dual-speed PTO
|
| | |
| Ford 2.8L 4-cyl gasoline |
| Ford 2.8L 4-cyl LP gas |
| Ford 2.8L 4-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 17 gal [64.3 L]
|
| Hydraulic system: | 2 gal [7.6 L]
|
| | |
| Rear Type: | I
|
| Rear lift: | 1,250 lbs [567 kg]
|
| | |
| Rear PTO: | independent
|
| Rear RPMs: | 540/1000
|
| | |
| Wheelbase: | 74.5 inches [189 cm]
|
| Weight: | 3500 to 6717 pounds
|
| Front tire: | 6.00x16
|
| Rear tire: | 12x28
|
| full dimensions and tires ... | | | 881 Serial Numbers: |
| Location: | Left side of tractor, on top of transmission case behind the starter.
|
1957: 1001
1958: 11977
1959: 58312
1960: 105943
1961: 131427
1962: 155531
how to read serial numbers...
|
|
|
|
| | Ford 881 Power: |
| Engine: | 62.6 hp [46.7 kW]
|
| Belt (claimed): | 40 hp [29.8 kW]
|
| Plows: | 3 (14-inch)
|
| Drawbar (tested): | 37.02 hp [27.6 kW]
|
| PTO (tested): | 46.16 hp [34.4 kW]
|
| power test details ... | | | Mechanical: |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| | power assist optional
|
| Brakes: | differential mechanical expanding shoe
|
| Cab: | Open operator station.
|
| | Hydraulics: |
| Type: | open center
|
| Capacity: | 2 gal [7.6 L]
|
| Pressure: | 2000 psi [137.9 bar]
|
| Total flow: | 4 gpm [15.1 lpm]
|
| | Electrical: |
| Ground: | positive (6V)
|
| | negative (12V)
|
| Charging system: | generator
|
| Charging amps: | 20
|
| | Battery: |
| Number: | 1
|
| Volts: | 6 (gas/lp)
|
| | 12 (diesel)
|
| Amp-hours: | 80 (6V)
|
| | 135 (12V)
|
