Tractors > Ford > TW-20

Ford TW-20 Tests



Ford TW-20 tractor photo
1979 - 1983
TW Series
Row-Crop tractor
Series map:
TW-10
TW-20
TW-30
123.0hp
144.5hp
175.0hp
Nebraska Tractor Test 1300
TW-20 fuel use from test 1300
Nebraska Tractor Test 1300
Diesel 16-speed 2WD
March 22 - April 10, 1979
Link: Nebraska Tractor Test 1300 file
PTO performance
Power at rated engine speed135.60 hp
101.1 kW
Fuel use8.9 gal/hour
33.7 l/hour
Power at rated PTO speed131.43 hp
98.0 kW
Fuel use8.1 gal/hour
30.7 l/hour
Drawbar performance
Max power116.64 hp
87.0 kW
Fuel use8.9 gal/hour
33.7 l/hour
Gear 5PD used for power test.
Max pull14155 lbs
6420 kg
Gear 2PD used for pull test.
