| 1987 - 1992 |
55 Utility Series | Utility tractor |
|
Series map:
2155
2355
2555
55.0hp
64.0hp
77.0hp
Transmissions overview |
8-speed non-synchronized |
8-speed partially synchronized |
16-speed partial power shift |
8-speed power shuttle |
Transmission |
Transmission | John Deere Collar Shift (CST)
|
Type | non-synchronized
|
Gears | 8 forward and 4 reverse
|
Clutch | dry disc
|
Four gears with two forward and one reverse range. |
Transmission |
Transmission | John Deere Top-Shaft Synchronized (TSS)
|
Type | partially synchronized
|
Gears | 8 forward and 4 reverse
|
Clutch | dry disc
|
Four gears (1-4) with two ranges (I-II) and reverse range. Optional creeper range provides 12 forward and 8 reverse speeds. |
Speeds |
With 14.9-24 rear tires. |
|
Transmission |
Transmission | John Deere Hi-Lo Top-Shaft Synchronized (TSS)
|
Type | partial power shift
|
Gears | 16 forward and 8 reverse
|
Clutch | dry disc
|
Adds a hydraulic high-low power shift to the basic TSS transmission. |
Transmission |
Transmission | John Deere Collar Shift Reverser
|
Type | power shuttle
|
Gears | 8 forward and reverse
|
Adds a hydraulic reverse to the CST transmission. |
