John Deere 2520 Tests
|
|
| Tractor Tests | |
| NTTL 992: diesel Syncro-Range 2WD | |
| NTTL 993: diesel Powershift 2WD | |
| NTTL 1002: gasoline Powershift 2WD | |
| NTTL 1003: gasoline Syncro-Range 2WD |
| Nebraska Tractor Test 992 | |||
| |||
| Nebraska Tractor Test 992 | |
| Diesel Syncro-Range 2WD October 22 - 29, 1968 Link: Nebraska Tractor Test 992 file | |
| PTO performance | |
| Power at rated engine speed | 61.29 hp 45.7 kW |
| Fuel use | 4.0 gal/hour 15.1 l/hour |
| Power at rated PTO speed | 55.86 hp 41.7 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Drawbar performance | |
| Max power | 52.36 hp 39.0 kW |
| Fuel use | 4.0 gal/hour 15.1 l/hour |
| Gear 4 used for power test. | |
| Max pull | 6,650 lbs 3016 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 993 | |||
| |||
| Nebraska Tractor Test 993 | |
| Diesel Powershift 2WD October 22 - 29, 1968 Link: Nebraska Tractor Test 993 file | |
| PTO performance | |
| Power at rated engine speed | 56.28 hp 42.0 kW |
| Fuel use | 4.2 gal/hour 15.9 l/hour |
| Power at rated PTO speed | 51.98 hp 38.8 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Drawbar performance | |
| Max power | 45.98 hp 34.3 kW |
| Fuel use | 4.0 gal/hour 15.1 l/hour |
| Gear 4 used for power test. | |
| Max pull | 6,797 lbs 3083 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 1002 | |||
| |||
| Nebraska Tractor Test 1002 | |
| Gasoline Powershift 2WD March 12 - 21, 1969 Link: Nebraska Tractor Test 1002 file | |
| PTO performance | |
| Power at rated engine speed | 56.98 hp 42.5 kW |
| Fuel use | 5.5 gal/hour 20.8 l/hour |
| Power at rated PTO speed | 51.96 hp 38.7 kW |
| Fuel use | 4.8 gal/hour 18.2 l/hour |
| Drawbar performance | |
| Max power | 48.09 hp 35.9 kW |
| Fuel use | 5.7 gal/hour 21.6 l/hour |
| Gear 4 used for power test. | |
| Max pull | 7,080 lbs 3211 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 1003 | |||
| |||
| Nebraska Tractor Test 1003 | |
| Gasoline Syncro-Range 2WD March 13 - 28, 1969 Link: Nebraska Tractor Test 1003 file | |
| PTO performance | |
| Power at rated engine speed | 60.16 hp 44.9 kW |
| Fuel use | 5.8 gal/hour 22.0 l/hour |
| Power at rated PTO speed | 53.21 hp 39.7 kW |
| Fuel use | 5.0 gal/hour 18.9 l/hour |
| Drawbar performance | |
| Max power | 54.45 hp 40.6 kW |
| Fuel use | 5.6 gal/hour 21.2 l/hour |
| Gear 4 used for power test. | |
| Max pull | 7,151 lbs 3243 kg |
| Gear 9.73 used for pull test. | |
