John Deere 1520 Transmission


John Deere 1520 tractor photo
1968 - 1972
Utility tractor
Series:102015202020
1530
Transmissions overview
8-speed collar shift
16-speed two-speed power shift
8-speed power shuttle
Transmission
Type:collar shift
Gears:8 forward and 4 reverse
Clutch:dry disc
Four gears (1-4) in two ranges (I/II) plus reverse (R) range.
Speeds
1520  collar shift speeds
Transmission
Type:two-speed power shift
Gears:16 forward and 8 reverse
Clutch:dry disc
Four gears (1-4) in two ranges (I/II) plus reverse (R) range. Left-hand power shift lever on dash.
Speeds
1520  two-speed power shift speeds
Transmission
Type:power shuttle
Gears:8 forward and 4 reverse
Four gears (1-4) in two ranges (I/II) with left-hand reverser lever. Reverse only available in low (I) range.
Speeds
1520  power shuttle speeds
