Tractors > Allis Chalmers > 816B backhoe-loader

Allis Chalmers 816B



No photo available
1974 - 1976
Backhoe loader tractor
Production
ManufacturerAllis Chalmers
TypeBackhoe loader tractor
FactoryTopeka, Kansas, USA
Allis Chalmers 816B Engine
Perkins 4.1L 4-cyl diesel
Engine details ...
Allis Chalmers 816B Transmission
4-speed power shuttle
Transmission details ...
Allis Chalmers 816B Power
Engine (net)83 hp
61.9 kW
Mechanical
Chassis4x2 2WD
Steeringpower
CabFour-post ROPS.
Photos
No photos of the Allis Chalmers 816B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel30 gal
113.6 L
Hydraulic system50 gal
189.3 L
Hydraulics
Typeopen center
Capacity50 gal
189.3 L
Pump flow25 gpm (loader)
94.6 lpm
 15 gpm (backhoe)
56.8 lpm
Steering flow5.5 gpm
20.8 lpm
Steering press.1500 psi
103.4 bar
Dimensions & Tires
Wheelbase88 inches
223 cm
Weight15500 lbs
7030 kg
Front tire11.00x16
Rear tire16.9x24
Full dimensions and tires ...
Backhoe & Loader
Dig depth195 inches
495 cm
Loader/Backhoe details ...
Electrical
Charging systemalternator
Battery volts12
References
816B reference literature
816B 715 Backhoe/Loader published in 1975, by Allis Chalmers
816B Backhoe Loader published in 1974, by Allis Chalmers
