Allis Chalmers 715B


Allis Chalmers 715B backhoe photo
1978 - 1980
Backhoe loader tractor
Series map:
714B
715B
72.0hp
72.0hp
Production
ManufacturerAllis Chalmers
Backhoe loader tractor
Variants
714B14-ft backhoe
715B15-ft backhoe
Allis Chalmers 715B Power
Engine (gross)72 hp
53.7 kW
Engine (net)65 hp
48.5 kW
Mechanical
Two-wheel drive
Power steering
Mechanical wet disc brakes
Four-post ROPS. Cab optional with heater.
Capacity
Fuel20 gal
75.7 L
Hydraulic system27 gal
102.2 L
Hydraulics
Typeopen center
Capacity27 gal
102.2 L
Pressure2450 psi
168.9 bar
Pump flow18 gpm
68.1 lpm
 11.3 gpm
42.8 lpm
Steering flow5 gpm
18.9 lpm
Steering press.1250 psi
86.2 bar
Dimensions & Tires
Wheelbase84 inches
213 cm
Weight13000 lbs
5896 kg
Front tire11Lx16
Rear tire16.9x24
Full dimensions and tires ...
Backhoe & Loader
Dig depth180 inches
457 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps42
Battery volts12
References
715B references literature
715B Backhoe Loader published in 1980, by Allis Chalmers
