Tractors > Belarus > T25LB backhoe-loader

Belarus T25LB

Belarus T25LB backhoe photo
1979 - 1987
Backhoe loader tractor






Production:

Manufacturer:Belarus
Factory:Minsk, Belarus
Original price (USD):8000 (1987)


Belarus T25LB Engine:

   Belarus 2.1L 2-cyl diesel
full engine details ...


Capacity:

Fuel:14 gal [53.0 L]
Hydraulic system:2 gal [7.6 L]


3-Point Hitch:

Rear Type:II
Rear lift:1350 lbs [612 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:540@1775


Dimensions & Tires:

Wheelbase:69 inches [175 cm]
Weight:7,055 lbs [3200 kg]
Front tire:6x16
Rear tire:10x28
full dimensions and tires ...


Backhoe & Loader:

Dig depth:99.2 inches [251 cm]
Dump angle:44 inches [111 cm]
full backhoe/loader specifications ...


T25LB Serial Numbers:


how to read serial numbers...



Belarus T25LB Power:

Engine:28 hp [20.9 kW]


Mechanical:

Chassis:4x2 2WD
Differential lock:mechanical rear
Steering:manual
Brakes:mechanical band
Cab:Four-post ROPS.


Hydraulics:

Type:open center
Capacity:2 gal [7.6 L]
Pressure:1420 psi [97.9 bar]
Valves:1
Pump flow:3.5 gpm [13.2 lpm] (tractor)
 30 gpm [113.6 lpm] (loader/backhoe)


Electrical:

Charging system:alternator
Charging amps:28


Battery:

Number:2
Volts:6
